The Iridium Portable Auxiliary Antenna is helps to improve your satellite reception in-vehicle and is compact enough to fit in your pocket. Easily attach it to your vehicle, recreational vehicle or other metal surface using the magnetic mount. Or attach the Iridium Portable Auxiliary Antenna to your satellite phone using the appropriate Antenna Adapter (sold separately), or to the portable dock.
Technical Specifications & Features
- Frequency: 1616-1626 MHz
- Polarization: RHCP
- Antenna element peak gain: 1 dBic (typical)
- Efficiency: 50%
- Bandwidth (-1dB): 30 MHz
- Axial Ratio: 2 dB (max)
- VSWR: 1.5 (max)
- Impedance: 50 Ohm
- Operating temp.: from -40 °C to 85 °C
- RF connector: TNC
Requires Adaptor Accessory for the specific model of Iridium phone: Iridium Extreme (9575), Iridium 9555, or Iridium 9500/9505/9505A (sold separately).
